Product information

Details

Application:

ReCoila GEN III FD Series reels are primarily designed for use in food and drink processing facilities to dispense CO2 / Nitrogen gases; blanketing vats and tanks during transfer, storage, fermentation and other processes.

A non-food grade model is also available for applications such as filling tyres.

Hose Type: Clear TMP hose. Food grade models comply with ASO1436, DNV, ABS, GL, BV, NKK, RINA, MSHA2

Media: Air, nitrogen, inert gases, CO2

Minimum Temperature: -30°C

Maximum Temperature: 65°C

Max PSI: 240 (High pressure non-food grade model is rated to 600PSI)

Fitting Type: BSP

Weight: 12kg

 FD Series
Model Hose ID Hose Length Inlet Fitting Outlet Fitting
FD620
 6mm
 20m
 3/8" BSPF
 1/4" BSPM
FD820
 8mm
 20m
 3/8" BSPF 3/8" BSPM
FD1020
 10mm
 20m 3/8" BSPF 3/8" BSPM
N1015 (High pressure non-food grade model) 10mm
 15m
 3/8" BSPF 3/8" BSPM
