Product information
Details
BT Weld FREEDOM 300 COMPACT 240V is a compact multi-process inverter welder for synergic or manual MIG, MMA and DC Lift-TIG work in fabrication and workshop environments.
Key Features
- Synergic and manual MIG gas and gasless welding
- MMA (stick) and DC Lift-TIG capability
- Up to 300 A output
- 40% duty cycle
- 5-inch colour LCD
- 2T, 4T and spot welding modes
- Suitable for mild steel, stainless steel, brass, copper and aluminium
- IP21S-rated enclosure with integrated tool storage
| WELDING | |
| Processes | MIG gas/gasless, MMA (stick), DC Lift-TIG |
| Maximum output | 300 A |
| Duty cycle | 40% |
| POWER AND CONTROL | |
| Primary input voltage | 240 V, single-phase |
| Display | 5-inch colour LCD |
| Control modes | Synergic and manual |
| Operating modes | 2T, 4T, spot |
| Stick Specifications | |
| Stick maximum material thickness | Mild steel / stainless steel: up to 14 mm |
| Stick electrode range | 1.6–5 mm |
| TIG Specifications | |
| TIG maximum material thickness | Mild steel / stainless steel: up to 8 mm |
| MIG Specifications | |
| MIG maximum material thickness | Mild steel: up to 12 mm; stainless steel: up to 10 mm; aluminium: up to 8 mm |
| Machine Specifications | |
| Input frequency (Hz) | 50/60 |
| Input voltage tolerance | ±15% |
| Supply plug | Not supplied |
| Plug approval | AS approved |
| Plug construction | Heavy duty |
| Plug installation | Electrician required |
| Recommended supply plug | 15 A, single-phase |
| Size and Weight | |
| Weight (kg) | 50.5 |
| Packaged weight (kg) | 55 |
| Dimensions (mm) | 960 × 465 × 925 |
Machine specifications
| MIG wire spool size | 5kg (D200); 15kg (D300) |
|---|
